System Specifications
Accelerator8x Positron Archer Transformer Accelerators
Memory per Accelerator32 GB HBM Each
Total Memory
For All Accelerators256 GB Each
For All Accelerators256 GB Each
System memory24-Channel RDIMM DDR5, 24 x 16GB DIMMs = 384 GB Can support up to 2TB system memory.
System Storage1x 1.92TB NVMe M.2, PCIe Gen3 x4 interface (OS/boot drive)
Data Storage1x 1.92TB U.2 2.5” SSD (model storage drive) Four total 2.5" SATA/SAS hot-swappable bays
CPUDual AMD® EPYC® Genoa 9374F Processors
64 Cores total, 3.85 GHz (Base)
4.3 GHz (Max Boost)
64 Cores total, 3.85 GHz (Base)
4.3 GHz (Max Boost)
Networking1x 10Gb/s LAN port (X550 Compatible)
Management Network1x 1Gb/s LAN port (Intel® I210-AT)
SoftwarePositron Inference Engine, Ubuntu 22.04.4 LTS (Jammy)
System Power Usage/PSU2+2 2000W Redundant Titanium Level (96%) power supplies
Expansion2x FHFL PCIe Gen5 x16 slots for GPUs, NICs, etc.
1x FHHL PCIe Gen4 x16 slot
1x FHHL PCIe Gen4 x16 slot
System dimensionsHeight: 7.0in (177mm)
Width: 19.0in (482.2mm)
Length: 29.25” (743mm)
Width: 19.0in (482.2mm)
Length: 29.25” (743mm)
System weight100 pounds (45.4 kg)
Support24h SLA Response Time from Washington-/US-based team
Increased density for power-constrained racks
Based on V1.1 power and performance.
Mixtral 8x7B Performance
DGX-H100
Atlas α
Aggregate Tokens per Second (TPS)
744
4400
Number of Users
8
40
DGX-H100
5,900 WAtlas α
Atlas α
Atlas α
Atlas α
Atlas α
01
02
03
